AL5900A3B-E6 Avaya 5952GTS-PWR+ 48-Ports SFP+ Gigabit Ethernet Switch
AL5900A3B-E6 Overview
Next-generation, high-performance, feature-rich Ethernet Switch platforms specifically optimized for the Wiring Closet demands of the high-performance Enterprise. Extreme Ethernet Routing Switch 5900 products deliver the agility to perform equally in conventional IP and Ethernet Fabric-based networking solutions. The Ethernet Routing Switch 5900 products leverage the latest advances in network switching architecture design to maximize hardware performance and software capability.
AL5900A3B-E6 Technical Specifications
Avaya 5952GTS-PWR+ 48-Ports SFP+ Gigabit Ethernet Routing Switch Layer 3 Rack-Mountable
Manufacturer Part Number: AL5900A3B-E6
Brand Name: Avaya
Product Type: Layer 3 Switch
Interfaces/Ports
Total Number of Network Ports: 52
Uplink Port: Yes
Modular: Yes
Stack Port: Yes
Media & Performance
Media Type Supported: Optical Fiber=, Twisted Pair
Ethernet Technology: Gigabit Ethernet, 10 Gigabit Ethernet
Network Technology: 1000Base-T, 10GBase-X
I/O Expansions
Number of Total Expansion Slots: 6
Expansion Slot Type: SFP+
Shared SFP Slot: No
Number of SFP+ Slots: 4
Network & Communication
Layer Supported: 3
Management & Protocols
Manageable: Yes
Power Description
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Physical Characteristics
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Height: 1.7″
Width: 17.3″
Depth: 20″
Weight: (Approximate) 15.67 lb
