ALTV244175ULCB3 Altronix 115VAC CCTV Power Supply

ALTV244175ULCB3 Technical Specifications

Altronix CCTV Power Supply, 4 PTC Class 2 Outputs, 24/28VAC @ 7A, 115VAC, BC200 Enclosure, Includes 3-wire line cord

Manufacturer: Altronix
Part Number: ALTV244175ULCB3
Brand Name: Altronix
Product Type: Proprietary Power Supply
Power Supply Type: Cabinet
# of Outputs: 4
Output Protection: PTC
Input Voltage: 110 V AC
Output Voltage: 24 V AC @ 7 A , 28 V AC @ 6.25 A
Form Factor: Wall Mount
Height: 12.3″
Width: 7.3″
Depth: 4.5″
Weight: 11.10 lb
Environmentally Friendly: Yes
Environmental Certification: RoHS
