ASR1002X-36G-SHAK9 Cisco ASR1002-X, 36G, Sec Bundle, K9, AES license

ASR1002X-36G-SHAK9 Technical Specifications

Cisco ASR1002-X, 36G, Sec Bundle, K9, AES license

Performance: Bandbreite: 36 Gbps ¦ Verschlüsselungsdurchsatz: 4 Gbit/s
Encryption Algorithm: Dreifach DES, AES
RAM: 8 GB (installiert) / 16 GB (Max)
Authentication Method: Secure Shell (SSH)
Network / Transport Protocol: L2TP, IPSec
Compliant Standards: CISPR 24, EN55022, VCCI Klasse A ITE, EN55024, CISPR 22, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 60950-1, AS/NZ 3548 Class A, ICES-003 Klasse A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, EN 300 386
Data Link Protocol: Gigabit Ethernet
Features: Firewall, NAT Support, VPN-Support, MPLS-Unterstützung, IPv6-Unterstützung, Stateful switchover (SSO), Unterstützung für Access Control List (ACL), Quality of Service (QoS), MPLS VPN, Software-Redundanz
Construction: original
Connectivity Technology: Wired
Enclosure Type: Desktop, an Rack montierbar – modular – 2U
Interfaces: Verwaltung: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ Verwaltung: 1 x Konsole – RJ-45 ¦ Verwaltung: 1 x Zusatz – RJ-45 ¦ 6 x Ethernet 1000 – SFP (mini-GBIC) ¦ USB: 2 x 4-polig USB Typ A
Remote Management Protocol: Telnet, SNMP 3, SSH
