C1300-24XS Cisco Catalyst 1300 24x SFP+ 10GBase-X Switch
C1300-24XS Overview
The Cisco Catalyst C1300-24XS is a 24-port SFP+ 10 Gigabit Ethernet switch designed to deliver high-speed connectivity, scalability, and secure network operations for modern enterprises, data centers, and service providers. With 24x SFP+ 10GBase-X ports, it provides flexible fiber uplinks and aggregation capabilities, making it ideal for high-bandwidth applications, server connectivity, and demanding workloads.As part of the Cisco Catalyst 1300 Series, this switch combines advanced Layer 3 routing, enterprise-grade security, and simplified management to support evolving business needs. It runs on Cisco’s intent-based networking architecture, supporting automation, analytics, and secure segmentation for optimized network performance.
C1300-24XS Technical Specifications
Cisco Catalyst 1300 24x SFP+ 10GBase-X Switch
Manufacturer Part Number: C1300-24XS
Brand Name: Cisco
Product Line: Catalyst 1300 Series
Product Type: Managed Gigabit Ethernet Switch
Total Ports: 24
10-Gigabit Ethernet Ports: 24 x 10G SFP+
Uplink Ports: Shared within 24 SFP+ slots (no dedicated uplinks)
Switching Capacity: 480 Gbps
Forwarding Rate: 357 Mpps
Layer Support: Layer 2 / Layer 3
MAC Address Table: 32,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: STP, RSTP, MSTP
Routing: Static IPv4 / IPv6, RIP, OSPF (limited L3)
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service (QoS): 8 queues, DSCP, IEEE 802.1p
Security: 802.1X, ACLs, Port Security, DHCP Snooping, DoS Prevention
Management: Web UI, CLI, SNMP, RMON
Port Mirroring: Supported
