C9200CX-12P-2X2G-E Cisco Catalyst 9200CX 12x Network Switch
C9200CX-12P-2X2G-E Overview
The Cisco Catalyst C9200CX-12P-2X2G-E is a compact, enterprise-grade Layer 3 managed switch designed for environments that need powerful performance in a small, silent form factor. With 12 Gigabit PoE+ ports, it can efficiently power wireless access points, IP phones, and surveillance cameras without external injectors. A 240W PoE budget ensures flexibility for multiple high-power devices across the network.
C9200CX-12P-2X2G-E Technical Specifications
Cisco Catalyst 9200CX 12x 10/100/1000 PoE+ & 2x 1000Base-T with 2x 10 Gigabit SFP+ uplink Ports Layer 3 Network Switch
Manufacturer: Cisco
Manufacture Part Number: C9200CX-12P-2X2G-E
Type: Layer 3 Managed Network Switch
Form Factor: Compact, fanless, rack/wall/desk mountable
Ports: 12 x 10/100/1000 RJ-45 Gigabit Ethernet
PoE: PoE+ support, up to 30W per port
Total PoE Budget: 240W (model dependent)
Additional Ports: 2 x 1G RJ-45 uplinks
Uplink Ports: 2 x 10G SFP+ uplinks
Switching Capacity: 80 Gbps
Forwarding Rate: 59.5 Mpps
Stacking: Not supported (standalone model)
Security: 802.1X, DHCP snooping, Dynamic ARP inspection, ACLs
Management: CLI, Web UI, SNMP, Cisco DNA Center support
Power Supply: Internal (fanless, silent operation)
Cooling: Passive cooling (no fan)
Dimensions: Compact design, ideal for limited-space deployments
