C9300-48H-A Cisco Systems Catalyst 9300 48-Port Upoe+

C9300-48H-A Overview

The Cisco® Catalyst® 9300 Series switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry’s most widely deployed switching platform. Catalyst 9300 Series switches form the foundational building block for Software-Defined Access (SD-Access), Cisco’s lead enterprise architecture. At up to 480 Gbps, they are the industry’s highest-density stacking bandwidth solution with the most flexible uplink architecture. The Catalyst 9300 Series is the first optimized platform for high-density Wi-Fi 6 and 802.11ac Wave2.

$5,299

Buy Now
Availability: In Stock
SKU:C9300-48H-A
Brand:

C9300-48H-A Technical Specifications

Cisco Systems Catalyst 9300 48-Port Upoe+ Network Advanced

Manufacturer Part Number: C9300-48H-A
Product Type: Ethernet Switch
Manageable: Yes
Ethernet Technology: Gigabit Ethernet
Number of Total Expansion Slots: 1
Product Family: Catalyst 9300
Stack Port: Yes
Media Type Supported: Twisted Pair, Optical Fiber
Total Number of Network Ports: 48
PoE (RJ-45) Port: Yes
Redundant Power Supply Supported: Yes
Expansion Slot Type: Uplink Module
Plug / Connector Type: IEC 60320 C16, C15, IEC 60320 C14
Form Factor: Rack-mountable
Power Consumption: 1100 W
Power Source: Power Supply
Layer Supported: 3
Environmentally Friendly: Yes
Number of Power Supplies Supported: 2
Number of Power Supplies Installed: 1
Modular: Yes
Uplink Port: Yes
PoE Budget: 822 W
Height: 1.7″
Width: 17.5″
Depth: 19.2″
Product Series: 9300
Product Model: C9300-48H
Product Line: Catalyst
