C9300L-24P-4X-A Technical Specifications
Cisco Catalyst 9300L Network Advantage switch 24 port
Capacity
Type :ACL scale entries
Type :FNF entries
Value :64000
Type :IPv4 routes
Value :32000
Type :IPv6 routes
Value :16000
Type :Multicast scale
Value :8000
Type :Packet buffer size
Value :16 MB
Type :QoS scale entries
Value :5120
Type :Switched virtual interfaces (SVIs)
Value :1000
Type :Virtual networks
Value :64
Type :VLANs supported
Value :4094
Dimensions & Weight
Depth :1.7 in
Height :19.2 in
Weight :15.01 lbs
Width :17.5 in
Environmental Parameters
Humidity Range Operating :5 – 90% (non-condensing)
Humidity Range Storage :5 – 90% (non-condensing)
Max Operating Temperature :113 °F
Max Storage Temperature :158 °F
Min Operating Temperature :23 °F
Min Storage Temperature :-40 °F
Flash Memory
Installed Size :16 GB
