C9500-32QC-E, Cisco Catalyst 9500 Series Switch

C9500-32QC-E Technical Specifications

Cisco Catalyst 9500 100/40-G 32-port switches: C9500-32C, C9500-32QC

Capacity
Type :FNF entries
Value :96000
Type :Host IPv4 routes
Value :90000
Type :Host IPv6 routes
Type :Indirect IPv4 routes
Value :212000
Type :Indirect IPv6 routes
Type :Multicast scale
Value :32000
Type :QoS ACL scale
Value :16000
Type :Routing table entries
Value :80000
Type :Security ACL scale
Value :270000
Type :Switched virtual interfaces (SVIs)
Type :VLAN IDs
Value :4000
Dimensions & Weight
Depth :18 in
Height :1.7 in
Weight :21.85 lbs
Width :17.5 in
Environmental Parameters
Humidity Range Operating :5 – 90% (non-condensing)
Humidity Range Storage :5 – 95% (non-condensing)
Max Operating Temperature :104 °F
Max Storage Temperature :149 °F
Min Operating Temperature :32 °F
Min Storage Temperature :-4 °F
