CCR1036-12G-4S Mikrotik RouterBoard Extreme Performance Cloud Core

CCR1036-12G-4S Overview

CCR1036-12G-4S is an industrial grade router with cutting edge 36 core CPU. If you need many millions of packets per second – Cloud Core Router with 36 cores is your best choice. The device comes in a 1U rackmount case, has four SFP ports, twelve Gigabit ethernet ports, a serial console cable and a USB port.


Buy Now
Availability: In Stock

CCR1036-12G-4S Technical Specifications

Mikrotik RouterBoard Extreme Performance Cloud Core Router with 12 10/100/1000 Ethernet ports, 4 SFP ports and RouterOS

Manufacture : MikroTik
Manufacture Part Number :
Number of Ports : 12
Technology : Ethernet
Number of SFP Ports : 4
Architecture TILE
CPU TLR4-03680
CPU core count 36
CPU nominal frequency 1.2 GHz
Dimensions 443 x 193 x 44 mm
RouterOS license 6
Operating System RouterOS
Size of RAM 4 GB
Storage size 1 GB
Storage type NAND
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -20°C to 60°C
IPsec hardware acceleration Yes
Powering Details
Number of AC inputs 2
AC input range 100-240
Max power consumption 60 W
Cooling type 2 fans
