CCR2004-16G-2S+PC MikroTik Cloud Core 16 Port Gigabit 2SFP+ Passive Cooling Router
CCR2004-16G-2S+PC Overview
MikroTik’s RB-CCR2004PC is a carrier-grade Cloud Core router powered by a 4-core ARM64 CPU. The unit comes equipped with installed RouterOS L6 and 4GB of onboard RAM. It features 16x Gigabit Ethernet ports as well as 2x SFP+ uplink ports and can be powered by either the DC Jack or a 2-pin terminal connection. Each group of 8x Gigabit Ethernet ports is connected to a separate switch chip which has a 10Gbps full-duplex line connected to the CPU. The SFP+ Ports also have a separate 10Gbps full-duplex line to prevent bottlenecks.
$529
CCR2004-16G-2S+PC Technical Specifications
MikroTik Cloud Core 16 Port Gigabit 2SFP+ Passive Cooling Router
Product code: CCR2004-16G-2S+PC
CPU: AL32400 1.2 GHz
CPU architecture: ARM 64bit
CPU core count: 4
Size of RAM: 4 GB
RAM type: DDR4
Storage: 128 MB, NAND
Number of 1G Ethernet ports: 16
Number of 10G SFP+ ports: 2
Operating system: RouterOS v7, License level 6
Switch chip model: 88E6191X
Number of Gbit ports per switch (there are two switch-chips): 8
Dimensions: 272 x 195 x 44 mm
Operating temperature: -20°C to +60°C
Number of DC inputs: 2
Supported input voltage: 36-57 V (DC jack) 36-57 (2-pin terminal)
Power adapter: Not Included with AU/NZ version
Max power consumption (without attachments): 30 W
Max power consumption: 36 W
Rack Mountable: Yes, standard 19″ kit included
Certification: CE, FCC, IC
