Refurbished CGS-2520-16S-8PC Cisco 2520 Connected Switch 8 Ports

Refurbished CGS-2520-16S-8PC Technical Specification

Cisco 2520 Connected Switch 8 Ports

Manufacturer :CISCO DS HARDWARE DIRECT
Brand :Cisco
Product Line :Cisco
Model :2520 Connected Grid Switch
Packaged Quantity :1
RAM
Technology :DDR2 SDRAM
Installed Size :256 megabyte
Performance
Performance :Bandwidth: 8 Gbps, Forwarding performance: 6.5 Mpps
Capacity
Capacity :IGMP groups: 1000, MAC addresses: 8000
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :Fast Ethernet
Form Factor :Desktop, Rack-mountable
Ports Qty :8
Manageable :Yes
Remote Management Protocol :CLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3
Power Over Ethernet (PoE) :PoE
Status Indicators :Alarm, Port status, Power, System
Features :Class of Service (CoS), DHCP snooping, Link Aggregation Control Protocol (LACP), Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Uni-Directional Link Detection (UDLD), VLAN support
Compliant Standards :IEEE 802.3af, IEEE 802.3i, IEEE 802.3u
Ports
Qty :8
Type :10/100 (PoE)
Ports (2nd)
Qty :16
Type :SFP (mini-GBIC)
Ports (3rd)
Qty :2
Type :Combo Gigabit SFP
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SD Memory Card
Interface Provided
Interfaces :18 x SFP (mini-GBIC), 2 x 1000Base-T RJ-45, 2 x console RJ-45 management, 8 x 100Base-TX RJ-45 PoE
Software
Type :Cisco IOS LAN Base
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Installed Qty :0
Max Supported Qty :2
