Refurbished CISCO3845-HSEC/K9 Technical Specifications
Cisco 3845 Router with Enhanced Security Bundle
General Information
Manufacturer Cisco Systems, Inc
Manufacturer Part Number CISCO3845-HSEC/K9
Brand Name Cisco
Product Series Cisco 3800
Product Model CISCO3845
Product Name 3845 Router with Enhanced Security Bundle
Product Type Router
Interfaces/Ports
Total Number of Ports 2
USB Yes
Management Port Yes
Number of Network (RJ-45) Ports 2
I/O Expansions
Number of Total Expansion Slots 15
Expansion Slot Type NME
Expansion Slot Type HWIC
Expansion Slot Type AIM
Expansion Slot Type PVDM
Expansion Slot Type SFP (mini-GBIC)
Network & Communication
Network Technology 10/100/1000Base-T
Ethernet Technology Gigabit Ethernet
Management & Protocols
Security Features
AIM-based security acceleration
Multiprotocol Label Switching (MPLS) VPN support
Secure Shell
Easy VPN Client and Server
Integrated hardware for offload of encryption services processing supports IPSec DES, 3DES, and AES 128, AES 192, and AES 256 ncryption modes
Threat Defense:
Cisco IOS Firewall
Transparent Firewall
Intrusion Detection
Intrusion Prevention
URL Filtering
Trust and Identity:
Network Admission Control (NAC)
Authentication, Authorization, and Accounting (AAA)
802.1x Support
Network Device Protection:
Control Plane Policing
AutoSecure
Network-Based Application Recognition (NBAR)
Memory
Standard Memory 512 MB
Maximum Memory 1 GB
Memory Technology DRAM
Flash Memory 128 MB
Power Description
Input Voltage 110 V AC
Input Voltage 220 V AC
Power Source Power Supply
Miscellaneous
Package Contents
3845 Router
25 SSL vpn Licenses (FL-WEBVPN-25-K9)
Cisco 3845 IOS ADVANCED IP SERVICES
Device manager for routers (ROUTER-SDM)
DES/3DES/AES VPN Encryption/Compression (AIM-VPN/SSL-3)
Cisco 3845 motherboard (CISCO3845-MB)
512MB DRAM default memory for 3800 (MEM3800-256U512D)
128MB Cisco 3800 Compact Flash Memory Default (MEM3800-64U128CF)
Cisco 3845 Power Supply blank panel (C3845-PS-BLANK)
Blank WAN Interface Card Panel (WIC-BLANK-PANEL)
Cisco 2800 and 3800 Series Blank network module panel (NM-28/38BLNK-PANEL)
Cisco 3845 AC power supply (PWR-3845-AC)
Power Cord, 110V (CAB-AC)
RJ-45-to-DB-9 console cable and RJ-45-to-DB-25 modem cable for management access
One 2.54-mm (0.100 in.) centerline, single row shunt
Ground lug and two mounting screws
One pair of rack-mount brackets with screws for 19-inch (48.26-cm) rack (screws are for bracket-to-chassis attachment)
One pair of brackets for 19-inch (48.26-cm) rack (screws are for bracket-to-chassis attachment)
Cisco Product Registration Card
Cisco 3800 Series Integrated Services Routers Regulatory Compliance and Safety Information document
Cisco Router and Security Device Manager (SDM) Quick Start Guide document
Cisco 3800 Series Integrated Services Routers Quick Start Guide
Additional Information
Network-Module slots:
These slots can accommodate a standard network-module, enhanced-network-module (NME), enhanced-extended-network-module (NME-X), and high-density extension module (EVM-HD)
Maximum number of network modules, NMEs, and NME-Xs supported: 4
Maximum number of NMD/NME-XDs supported: 2
Maximum number of EVM-HDs supported: 2
HWIC slots:
These slots also support VICs, VWICs, and WICs
PVDM slots:
These slots accommodate digital-signal-processor (DSP) modules for packet voice processing
Rack-Mounting:
National Equipment Building Standard (NEBS)/European Telecommunication Standards Institute (ETSI) options
Operation Altitude:
Up to 6500 ft (2000m), derate 1°C per 1000 ft
Noise Level:
56 dBa typical, 58 dBa maximum
Certifications & Standards
IEEE 802.3: 10BASE-T
IEEE 802.3u: 100BASE-TX
IEEE 802.3ab: 1000BASE-T
IEEE 802.1x: Authentication
USB 1.1
Safety:
UL 60950
CAN/CSA C22.2 No. 60950
EN 60950
AS/NZS 60950
EMC:
47 CFR, Part 15
ICES-003 Class A
EN55022 Class A
CISPR22 Class A
AS/NZS 3548 Class A
VCCI V-3
EN 300386
EN 61000
TELCOM:
47 CFR, Part 68
TIA/EIA/IS-968
CS-03
RTTE Directive
