CTP150-IM-SER Juniper CTP150-IM 4-Port Serial Interface Module
CTP150-IM-SER Overview
The Juniper Networks CTP150 Circuit to Packet platform optionally includes a replaceable CTP150–IM-SER serial interface module that can be paired with another module of the same type or a T1/E1 interface module. The serial interface module also has the option of supporting two multiservice daughter cards for 4-KHz or high-quality analog audio, or interrange instrumentation group (IRIG) signals
$4,119
CTP150-IM-SER Technical Specifications
Juniper Networks CTP150-IM 4-Port Serial Interface Module
Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :Interface Module
Packaged Quantity :1
Networking
Type :Expansion module
Form Factor :Plug-in module
Connectivity Technology :Wired
Data Link Protocol :RS-232, RS-422, RS-530, RS-530A, V.24, V.35, X.21
Ports
Qty :4
Type :RS-232/V.24/EIA530/530A/RS-422/499/X.21/V.35
Interface Provided
Interfaces :4 x RS-232/V.24/EIA530/530A/RS-422/499/X.21/V.35 – 26 pin HD D-Sub
Compatibility
Compatible With :Juniper Networks CTP150
