DC9DH Dell PowerSwitch S4048T-ON 48 x Ports 10GBase-T Switch
DC9DH Overview
The Dell PowerSwitch S4048T-ON (DC9DH) is a high-performance 10-Gigabit Ethernet switch designed for modern data centers and enterprise networks requiring ultra-low latency and high throughput. It features 48 10GBase-T ports, providing high-speed copper connectivity for servers, storage, and aggregation needs, with support for standard RJ-45 cabling.This switch offers Layer 3 routing capabilities, including dynamic routing protocols and inter-VLAN routing, enabling efficient traffic management and scalable network architectures. It supports advanced data center features such as VXLAN, OpenFlow, and automation-ready interfaces for programmability and integration into modern network infrastructures.
DC9DH Technical Specifications
Dell PowerSwitch S4048T-ON 48 x Ports 10GBase-T Switch
Manufacturer Part Number: DC9DH
Brand Name: Dell
Product Type: Managed Layer 3 10GbE Ethernet Switch
Total Ports: 48
Port Type: 48 x 10GBase-T RJ-45
Uplink Ports: Optional expansion via QSFP+
Switching Capacity: 1.44 Tbps
Forwarding Rate: 1,071 Mpps
Layer Support: Layer 2 / Layer 3
MAC Address Table: 512,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: STP, RSTP, MSTP
Routing: Static, OSPF, BGP, IPv4/IPv6
Link Aggregation: IEEE 802.3ad LACP
Quality of Service (QoS): 8 queues, DSCP, IEEE 802.1p
Security: 802.1X, ACLs, RADIUS, TACACS+, Port Security
Management: CLI, Web GUI, SNMP, OpenManage, REST API
High Availability: VRRP, ECMP, MLAG
Port Mirroring: Supported
