DS-HP-FC-K9 Technical Specifications
Cisco MDS 12port Fabric Switch
Manufacturer Part Number: DS-HP-FC-K9
Brand: Cisco
Type: MDS 12-Port Fibre Channel Fabric Switch
Ports: 12 x Fibre Channel ports (1/2/4 Gbps auto-sensing)
Layer: Layer 2 Fibre Channel switching
Management: Cisco Fabric Manager, CLI, SNMP, RMON, Telnet/SSH
VSAN: Virtual SANs supported
QoS: Class of Service (CoS), traffic prioritization
Security: Port security, ACLs, role-based access control, DH-CHAP
Switching Capacity: 48 Gbps
Forwarding Rate: Up to 24 Mpps
Hot Swap: Supported, hot-swappable power supplies and fans
Form Factor: 1U rack-mountable switch
LEDs: System, port link, activity, and power indicators
Redundant Power: Dual hot-swappable power supplies
Cooling: Hot-swappable fan modules, front-to-rear airflow
High Availability: Non-disruptive software upgrades (NDU), stateful failover
Fabric Services: Zoning, name server, traffic management, fabric security
Multicast: Fibre Channel multicast supported
