FTLD10CD3C Finisar TX/RX Optical Fiber 135.6Gbps 20-Pin SFP
FTLD10CD3C Overview
third-generation CXP optical transceiver modules are designed for use in data center, core-routing, and high-performance computing applications up to 135.6 Gigabit per second links over multimode fiber.
$695
Your Payment is 100% Secure
SKU:
FTLD10CD3C
Tags: 10 Gigabit Ethernet Transceiver, CXP Transceivers, MMF Connectivity, Transceiver
Categories: Finisar Transceivers
Brand: FINISAR
FTLD10CD3C Technical Specifications
TX/RX Optical Fiber 135.6Gbps 20-Pin SFP
Manufacturer: Finisar
12-channel full-duplex transceiver module
Hot Plug gable CXP footprint
Maximum link length of 300m on OM3 Multimode Fiber (MMF)
Multirate capability: 1.06Gb/s to 11.3Gb/s per channel 10 Gigabit Ethernet
Unretimed CPPI electrical interface
Requires 3.3V power supply only
Low power dissipation: <3.5W
Reliable VCSEL array technology
Digital Diagnostics including Tx and Rx optical power monitoring
Commercial operating case temperature range: 0°C to 70°C
