IE-1000-4T1T-LM Technical Specifications
Cisco Industrial Ethernet 1000 Series Switch 5 ports Managed
Product Type: Ethernet Switch
Manageable: Yes
Ethernet Technology: Fast Ethernet
Product Family: 1000
Stack Port: No
Media Type Supported; Twisted Pair
Total Number of Network Ports: 5
Form Factor: Rail-mountable
Power Source: Power Supply
Layer Supported; 2
Modular; No
Uplink Port: Yes
Port / Expansion Slot Details: 1 x Fast Ethernet Uplink, 4 x Fast Ethernet Downlink
Height: 5″
Width: 1.5″
Depth: 4.5″
Product Series: 1000
Product Model; IE-1000-4T1T-LM
Network Technology: 10/100Base-T
Technical Information
Humidity Range Storage: 5 – 95% (non-condensing)
Max Operating Temperature: 158 degree Fahrenheit
Max Storage Temperature: 185 degree Fahrenheit
Min Operating Temperature: -4 degree Fahrenheit
Min Storage Temperature: -40 degree Fahrenheit
MTBF: 374,052 Hours
Operating Humidity: 5 – 95% (non-condensing)
