JW669-61001 HPE Aruba 48-Ports SFP+ 10Gbps 100Base-T Switch
JW669-61001 Overview
The HPE Aruba JW669-61001 Mobility Access Switch is a high-performance Layer 3 managed switch designed to deliver 10GbE connectivity for modern enterprise and campus networks. With 48 SFP+ 10Gbps fiber ports and additional 10GBase-T uplink options, it provides robust, high-density aggregation suitable for mobility-driven infrastructures, wireless controller backhaul, and data center access. Offering a switching capacity of up to 1.28 Tbps and a forwarding performance of nearly 1 billion packets per second, it ensures seamless high-speed data transfers even under heavy workloads
JW669-61001 Technical Specifications
HPE Aruba 48-Ports SFP+ 10Gbps 100Base-T Mobility Access Switch
Manufacturer: HPE Aruba
Manufacture Part Number: JW669-61001
Form Factor: Rack-mountable 1U
Ports: 48 x SFP+ 10Gbps (fiber connectivity)
Additional Ports: 4 x 100/1000/10GBase-T (RJ-45) uplinks
Performance: Up to 1.28 Tbps switching capacity
Forwarding Rate: ~952 Mpps
Layer: Layer 3 managed
Stacking: VSF (Virtual Switching Framework) supported
Management: CLI, Web GUI, SNMP, Aruba AirWave, Aruba Central
MAC Address Table: 128K entries
Packet Buffer: 16 MB
Power Supply: Dual hot-swappable AC power supply supported
Cooling: Hot-swappable redundant fans
Operating Temperature: 0°C to 45°C
