JX945A HP Aruba Instant Iap-305 Rw In-Ceiling Access Point

SKU: JX945A Categories: , , GTIN: 0190017087719

JX945A Overview

The entry-level Aruba 300 Series Access Points (APs) deliver high performance and superb user experience for medium density environments. The 300 series APs enable an all wireless digital work environment in a cost effective manner. With a maximum concurrent data rate of 1,300 Mbps in the 5GHz band and 400 Mbps in the 2.4GHz band, the entry-level 300 series bring an always-on wireless network experience with the performance required for enterprises. It is ideal for cost sensitive medium density environments across verticals.

$379.00

JX945A Technical Specifications

HP Aruba Instant Iap-305 Rw In-Ceiling Access Point

Compliant Standards : IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, Wi-Fi CERTIFIED
Connectivity Technology : Wireless
Data Link Protocol : IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features : 2T2R MIMO technology, 3T3R MIMO technology, Advanced Cellular Coexistence (ACC), Aruba Beacons Bluetooth Low-Energy (BLE) technology, Auto-uplink (auto MDI/MDI-X), Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), DFS support, Enhanced ClientMatch, Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), MU-MIMO technology, Quality of Service (QoS), Reset button, Space Time Blocking Code (STBC), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Wireless intrusion protection
Form Factor : In-ceiling
Power Over Ethernet (PoE) : PoE
Spread Spectrum Method : DSSS, OFDM
Status Indicators : System, Wireless
Type : Wireless access point
Wi-Fi Bands : 2.4 GHz, 5 GHz
Wireless Protocol : 802.11a/b/g/n/ac
Interface Provided
Connector Type : RJ-45
Qty : 1
Type : 1000Base-T
Connector Type : Type A
Type : USB 2.0
Miscellaneous
Compliant Standards : CB, cTUVus, EN 300 328, EN 301 489, EN 301 893, EN 60601-1-1, EN 60601-1-2, EN 60950, FCC, IEC 60950, LVD 72/23/EEC, R&TTE Directive 1995/5/EC, UL 2043, UL 60950
Included Accessories : 2 x ceiling mounting clip
MTBF : 1,116,000 hours
Antenna
Antenna Form Factor : Internal
Antenna Qty : 3
Directivity : Omni-directional
Gain Level : 5.4 DBi
Environmental Parameters
Humidity Range Operating : 5 – 93% (non-condensing)
Max Operating Temperature : 122 °F
Min Operating Temperature : 32 °F
Header
Brand : Aruba
Compatibility : PC
Manufacturer : Aruba
Model : IAP-305 (RW)
Packaged Quantity : 1
Product Line : HPE Aruba Instant
Line Properties
Line Coding Format : 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, QPSK
OS Provided
Type : InstantOS
Power Device
Power Consumption Operational : 13 Watt
Capacity
Type : BSSIDs per radio
Value : 16
Type : Wireless clients per Wi-Fi radio
Value : 255
Dimensions & Weight
Depth : 6.5 in
Height : 1.5 in
Weight : 16.22 oz
Width : 6.5 in
Chassis
Ruggedized Design : Indoor
Performance
Type : Concurrent data rate (2.4 GHz)
Value : 400 Mbps
Type : Concurrent data rate (5 GHz)
Value : 1300 Mbps
Type : Peak data rate
Value : 1.7 Gbps
