L5-25239-22 LSI Logic Megaraid Pci Express Sata/sas Raid Controller

L5-25239-22 Technical Specifications

LSI Logic Megaraid 9261-8i 6gb 8port Pci Express 2.0 X8 Sata/sas Raid Controller With 512mb Cache

Device Type: Sas Raid Controller
Controller Interface Type: Serial Attached Scsi . Serial Ata/600
Interface Type : Pci Express 2.0 X8
Data Transfer Rate: 6gb/s Throughput Per Port
Form Factor: Low-profile Plug-in Card
Raid Level: Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Standard Memory: 512 Mb Ddr2 Sdram
Max Drive Support: 32
Ports: 2 X Sff-8087 Mini Sas 600 – Serial Attached Scsi Internal
