M280CS2140-1TB-RB PNY CS2140 1TB SSD M.2 2280 Internal (PCI Express NVMe)

M280CS2140-1TB-RB Technical Specifications

PNY CS2140 1TB SSD M.2 2280 Internal (PCI Express NVMe)

Brand PNY
Product Line PNY
Model CS2140
Manufacturer Pny Electronics

Storage
Compliant Standards
S.M.A.R.T.
Form Factor (Short) M.2
Form Factor (Short) (metric) M.2
Hard Drive Capacity 1 TB
Hard Drive Features
Active State Power Management (ASPM), Autonomous Power State Transition (APST), End-to-end data path protection, LDPC error correction, NVM Express (NVMe) 1.4, RAID 0+1 – factory configured, TRIM support
Hard Drive Type
Internal hard drive
HD Interface PCI Express 4.0 x4 (NVMe)
Max Internal Data Transfer Rate 3600 MBps
Max Write Transfer Rate 3200 MBps
Storage Interface
PCI Express 4.0 x4 (NVMe)

Connectivity
Interface Provided 1 x PCI Express 4.0 x4 (NVMe)

Technical Information
Compatible Bay M.2 2280
Hard Drive Form Factor M.2 2280
Hard Drive Form Factor (metric) M.2 2280
Encryption 256-bit AES
Max Operating Temperature
158 degree Fahrenheit
Max Storage Temperature
185 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
1,500,000 Hours

Product Information
Packaged Quantity 1
Product Type
Solid state drive

Dimensions & Weight
Height 0.2 inch
Weight 0.23 ounce
Width 0.9 inch
Depth 3.1 inch
