MA-ANT-3-B6 Cisco Meraki Antenna
MA-ANT-3-B6 Overview
This bendable dipole antenna offers 360-degree omnidirectional coverage, and is ideal for low ceiling installations where wall penetration or extended reach are important. Some example uses are low-density deployments like schools and hotels to provide basic low-performance connectivity.
$156
MA-ANT-3-B6 Technical Specifications
Cisco Meraki Antenna
General
Category of Accessory :Antenna
Miscellaneous
Compatible With :Cisco Meraki MR53
Antenna
Antenna Placing Mounting :Indoor
Directivity :Omni-directional
Form Factor :Dipole
Frequency Range :2.4 – 2.5 GHz, 5.15 – 5.875 GHz
Gain :3 dBi (for 2.4 GHz), 5.7 dBi (for 5 GHz)
Horizontal Beamwidth :360°
Intended For :Wi-Fi
Vertical Beamwidth :40°
Environmental Parameters
Humidity Range Operating :5 – 95%
Max Operating Temperature :104 °F
Min Operating Temperature :32 °F
Header
Brand :Cisco Meraki
Manufacturer :CISCO DS HARDWARE DIRECT
Packaged Quantity :6
Product Line :Cisco Meraki
Interface Provided
Connector Qty :1
Connector Type :RP-TNC Connector
Miscellaneous
Color Category :White
Product Material :ABS plastic
Product Type :Antenna
