MZ7LM480HMHQ-00005 Technical Specifications
Samsung Pm863a 480 Gigabyte (GB) Serial Advanced Technology Attachment (SATA) 6 Gigabytes Per Second (GBPS) 2.5 Inch Solid State Drive
Manufacturer: Samsung
Model Number or SKU# MZ7LM480HMHQ-00005
Product Type: Solid State Drive
Interface: SATA-6GBPS
Technical Information for SATA-6GBPS Solid State Drive
Storage Capacity: 480GB
MTBF: 2000000 Hours
Product Line: PM863A
Drive Dimensions: 2.5 Inch
Features: Trim Support, End-To-End Data Protection
3d V-Nand Technology, Dynamic
Thermal Guard Protection, Advanced ECC Engine
Performance of 480GB Solid State Drive
Drive Transfer Rate: 600 MBPS (External)
Internal Data Rate: 520 MBPS (Read) / 480 MBPS (Write)
4KB Random Read: 97000 IOPS
4KB Random Write: 16000 IOPS
Features for 6GBPS SSD
NAND type: Samsung V-NAND
Encryption support: AES 256-bit Encryption Engine
Allowable voltage: 5.0 V ± 5%
UBER7: 1 sector per 1017 bits read
Operating temperature: 0 – 70°C
Shock: 1500 G, duration 0.5 ms, Half Sine Wave
