MZPLL6T4HMLS-000D3 Samsung 6.4TB TLC PCI E NVMe (SSD)
MZPLL6T4HMLS-000D3 Overview
The Samsung PM1725a 6.4TB is an enterprise-grade NVMe solid-state drive designed for high-performance servers and data-center applications. Utilizing a PCI Express 3.0 x4 interface in a 2.5-inch form factor, it combines high-capacity storage with ultra-fast read/write performance suitable for virtualization, cloud infrastructure, large-scale databases, and other mission-critical workloads. Built with TLC V-NAND technology and a robust enterprise NVMe controller, the drive delivers consistent sequential and random I/O performance, ensuring low latency and reliable operation under continuous 24/7 workloads.
MZPLL6T4HMLS-000D3 Technical Specifications
Samsung PM1725a 6.4TB TLC PCI Express NVMe 3.0 x4 2.5-Inch Solid State Drive (SSD)
Manufacturer: Samsung
Manufacturer Part: MZPLL6T4HMLS-000D3
Capacity: 6.4TB
Form Factor: 2.5-inch (U.2, Enterprise NVMe)
Interface: PCIe 3.0 x4, NVMe
NAND Type: TLC (V-NAND)
Sequential Read: Up to 6,400 MB/s
Sequential Write: Up to 3,000 MB/s
Random Read (4K): Up to 800,000 IOPS
Random Write (4K): Up to 160,000 IOPS
Endurance: 5 DWPD
MTBF: 2,000,000 hours
Power Loss Protection: Yes
UBER: < 1 per 10^17 bits
Active Power: ~23W
Idle Power: ~7.7W
Operating Temp: 0°C – 70°C
