N-GXE-LC-02 Transition Networks Network Adapter PCIe 2.1 1000Base-SX x 2
N-GXE-LC-02 Overview
The Transition Networks N-GXE-LC-02 Fiber Gigabit Ethernet to PCIe Bus Adapter complies with all IEEE 802.3z and 1000Base-SX standards. It provides full-duplex bandwidth capacity to support high-end servers. With functions like VLAN filtering packet processing, link aggregation, smart load balancing, failover and Wake-on-LAN, this adapter provides enhanced performance, flexible configuration and secure networking for users in a standard-based environment. An LED indicator on the bracket displays link status, activity and speed to keep a tab on the functioning of the adapter.
$294
N-GXE-LC-02 Technical Specifications
Transition Networks Network Adapter PCIe 2.1 1000Base-SX x 2
Brand: Transition Networks
Product Line: Transition Networks
Model: N-GXE-LC-02
Manufacturer: Transition Networks
Network & Communication
Cable Type: Ethernet 1000Base-SX
Connectivity Technology: Wired
Data Link Protocols: Gigabit Ethernet
Data Transfer Rate: 1 GBps
Form Factor: Plug-in card
Host Interface: PCI Express 2.1 x1
Low Profile: Low profile
Max Transfer Distance (Optical): 1800 ft
Network Standard: TCP/IP, UDP/IP
PCI Specification Revision: PCIe 2.1
Product Type: Network adapter
Status Indicators: Link/activity
Connectivity
Interface Provided: 2 x 1000Base-SX – LC multi-mode
Port Quantity: 2
Network & Adapter Ports: 1000Base-SX
Power
Power Consumption Operational: 1.66 watt
Product Information
Packaged Quantity: 1
Service Activation: No
Included Items
Included Accessories: Low-profile bracket
Dimensions & Weight
Height: 2.2 inch
Weight: 8.82 ounce
Depth: 4.1 inch
