Refurbished N2K-C2248TP-E-1GE Technical Specifications
Cisco Nexus 2000 Fabric Extender
Manufacturer :CISCO DS HARDWARE DIRECT
Brand :Cisco
Product Line :Cisco Nexus
Model :2248TP-E GE Fabric Extender
Packaged Quantity :1
RAM
Installed Size :32 megabyte
Networking
Type :Fabric Extender
Form Factor :Rack-mountable
Connectivity Technology :Wired
Cabling Type :Ethernet 1000Base-T, Ethernet 100Base-TX
Data Link Protocol :Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol :ICMP/IP, TCP/IP, UDP/IP
Remote Management Protocol :RMON, SNMP 1, SNMP 2, SNMP 3
Status Indicators :Port status, Power, System
Features :Access Control List (ACL) support, Auto-negotiation, Flow control, Full duplex capability, Hot swap module replacement, IGMP snooping, IPv6 support, Jumbo Frames support, Quality of Service (QoS), Spanning Tree Protocol (STP) support, Syslog support, Uplink, VLAN support, Weighted Round Robin (WRR) queuing
Compliant Standards :IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x
Ports
Qty :48
Type :10/100/1000
Expansion Slots
Expansion Slots :4 (total) / 4 (free) x SFP+
Interface Provided
Interfaces :48 x 1000Base-T – RJ-45
Power Device
Power Consumption Operational :110 watt
Miscellaneous
Compliant Standards :AS/NZS 60950-1, BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1, EN 300 386, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN300-386, EN50082-1, EN55022 Class A, EN55024, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1, RoHS, UL 60950-1, VCCI Class A ITE
Dimensions & Weight
Width :17.3 inch
Depth :17.7 inch
Height :1.7 inch
Weight :17.64 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 95% (non-condensing)
