Refurbished N5K-C5596T-FA Technical Specifications
Cisco Nexus 5596T Layer 3 Switch
Manufacturer Cisco Systems, Inc
Manufacturer Part Number N5K-C5596T-FA-RF
Brand Name Cisco
Product Line Nexus
Product Series 500
Product Model 5596T
Product Name Nexus 5596T Layer 3 Switch
Product Condition Refurbished
Product Type Layer 3 Switch
Technical Information−
Interfaces/Ports
Total Number of Network Ports 32
Token Ring Port No
LRE Port No
Bypass No
Modular No
Management Port Yes
USB No
Stack Port No
Number of Network (RJ-45) Ports 32
Port/Expansion Slot Details 32 x 10 Gigabit Ethernet Network, 16 x 10 Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported Twisted Pair
Ethernet Technology 10 Gigabit Ethernet
Network Technology 10GBase-T, 10GBase-X
I/O Expansions
Number of Total Expansion Slots 19
Expansion Slot Type SFP+
Shared SFP Slot No
Number of SFP+ Slots 16
Network & Communication
Layer Supported 3
Management & Protocols
Manageable Yes
Management
SNMP v1, v2, v3
RMON
Telnet
CLI
QoS
VLAN
MIB
DHCP
Web Based Management
Power Description
PoE (RJ-45) Port No
Input Voltage 120 V AC, 230 V AC
Power Source Power Supply
Redundant Power Supply Supported Yes
Physical Characteristics
Compatible Rack Unit 2U
Form Factor Rack-mountable
Height 3.5″
Width 17.3″
Depth 29.5″
Weight (Approximate) 47.50 lb
Miscellaneous
Package Contents
Nexus 5596T Layer 3 Switch
2 x 1100W AC Power Supplies
4 x Fans
Certifications & Standards
CE Markings
2004/108/EC
2006/95/EC
Safety:
UL 60950-1 Second Edition
CAN/CSA-C22.2 No. 60950-1 Second Edition
EN 60950-1 Second Edition
IEC 60950-1 Second Edition
AS/NZS 60950-1
GB4943
Emissions:
47CFR Part 15 (CFR 47) Class A
AS/NZS CISPR22 Class A
CISPR22 Class A
EN55022 Class A
ICES003 Class A
VCCI Class A
EN61000-3-2
EN61000-3-3
KN22 Class A
CNS13438 Class A
Immunity:
EN55024
CISPR24
EN300386
KN 61000-4 series
IEEE Standards:
802.3
802.1D
802.1Q
802.3x
802.3ad
802.1w
802.3ae
802.1s
801.1p
802.1Qaz
802.1Qbb
Environmentally Friendly Yes
Environmental Certification RoHS-6
