Refurbished N7K-C7010-B2S2 Technical Specifications
Cisco Nexus 7010 Bundle switch
Brand :Cisco
Product Line :Cisco Nexus
Model :7010 Bundle
Bundled with :Cisco Nexus 7000 Series Supervisor 2 Module, 5x Cisco Nexus 7000 Series Fabric-2 Module
Packaged Quantity :1
Chassis
Installed Devices / Modules Qty :6
Supported Devices / Modules Qty :15
Processor
Type :Xeon
Installed Qty :1
Manufacturer :Intel
Clock Speed :2.13 GHZ
RAM
Installed Size :12 GB
Flash Memory
Installed Size :8 GB, 8 GB
Networking
Type :Switch
Subcategory :Network hubs and switches
Form Factor :Rack-mountable
Advanced Switching :Layer 3
Manageable :Yes
Remote Management Protocol :CLI, SNMP 1, SNMP 2c, SNMP 3
Features :Modular design
Expansion Slots
Expansion Slots :15 (total) / 9 (free) x expansion slot
Interface Provided
Interfaces :1 x console – RJ-45 management, 1 x console RJ-45, 3 x USB
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Installed Qty :0
Max Supported Qty :2
Miscellaneous
Height (Rack Units) :21
Compliant Standards :BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA, EMC, EN 300 386, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN300-386, EN50082-1, EN55022 Class A, EN55024, ETSI, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1, NEBS level 3, RoHS 5/6, UL, VCCI Class A ITE
Dimensions & Weight
Width :17.3 inch
Depth :33.1 inch
Height :36.5 inch
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Min Storage Temperature :-40 degree Fahrenheit
Max Storage Temperature :158 degree Fahrenheit
Humidity Range Operating :5 – 90% (non-condensing)
Humidity Range Storage :5 – 95% (non-condensing)
