N9K-C93180YC-ZZ-PE Cisco Systems Nexus 9300 48 Port 10/25G 6 Port
N9K-C93180YC-ZZ-PE Overview
The Cisco Nexus® 9300-EX platform is the next generation of the fixed Cisco Nexus 9000 Series Switches. Cisco Nexus 9300-EX platform switches are built on modern system architecture designed to provide high performance to meet the evolving needs of highly scalable data centers. They offer a variety of interface options available to transparently migrate existing data centers from 100-Mbps, 1-Gbps, and 10-Gbps speeds to 25 Gbps at the server, and from 10 and 40 Gbps to 50 and 100 Gbps at the aggregation layer.
$23,149
Buy NowN9K-C93180YC-ZZ-PE Technical Specifications
Cisco Systems Nexus 9300 48 Port 10/25G 6 Port 100G PT Side
Manufacturer Part Number; N9K-C93180YC-ZZ-PE
Product Type: Layer 3 Switch
Manageable: Yes
Ethernet Technology: 10 Gigabit Ethernet, 40 Gigabit Ethernet
Number of Total Expansion Slots: 54
Product Family: Nexus 9300
Media Type Supported: Optical Fiber
Redundant Power Supply Supported: Yes
Expansion Slot Type: SFP+, QSFP
Form Factor: Rack-mountable
Power Source: Power Supply
Layer Supported: 3
Environmentally Friendly: Yes
Compatible Rack Unit: 1U
Number of SFP+ Slots: 48
Modular: Yes
Shared SFP Slot: No
Port / Expansion Slot Details: 48 x 10 Gigabit Ethernet Expansion Slot, 6 x 40 Gigabit Ethernet Expansion Slot
Country of Origin: Mexico
Height: 1.7″
Width: 17.3″
Depth: 22.5″
Product Series; 9300
Product Model; 93180YC-EX
Network Technology: 10GBase-X, 40GBase-X
Product Line: Nexus
