P11691-001 Technical Specifications
HP 32-Ports QSFP28 1U Network Switch
Manufacturer Part Number: P11691-001
Brand Name: HP
Product Type: Managed 100GbE Switch
Total Ports: 32
100-Gigabit Ethernet Ports: 32 x QSFP28 (supports 40/100GbE, breakout to 4x 25GbE)
Switching Capacity: 6.4 Tbps
Forwarding Rate: 4,760 Mpps
Layer Support: Layer 2 / Layer 3 / Layer 4
MAC Address Table: 512,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Routing: Static, OSPF, BGP, IS-IS, IPv4/IPv6
Spanning Tree Protocols: STP, RSTP, MSTP
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service (QoS): 8 queues, DSCP, IEEE 802.1p
