P20007-S21 HPE 1.92TB PCI Express NVMe U.3 2.5-inch SSD
P20007-S21 Overview
The HPE P20007-S21 1.92TB PCI Express 4.0 x4 NVMe Read Intensive U.3 2.5-inch Internal Solid State Drive (SSD) with Smart Carrier is a high-performance enterprise-grade storage solution designed for HPE ProLiant Gen10 Plus and Gen11 servers. Utilizing the NVMe PCIe 4.0 x4 interface, it delivers ultra-fast data transfer speeds, reduced latency, and superior IOPS performance compared to traditional SATA or SAS drives.
Built for read-intensive workloads, this SSD offers a 1.92TB capacity, ideal for virtualization, cloud services, database analytics, and boot operations. The U.3 2.5-inch Small Form Factor (SFF) ensures compatibility with the latest server architectures, while the Smart Carrier provides LED indicators for activity and drive health, simplifying system monitoring and management.
P20007-S21 Technical Specifications
HPE 1.92TB PCI Express 4.0 x4 NVMe Read Intensive U.3 2.5-inch Internal Solid State Drive (SSD) with Smart Carrier
Part Number: P20007-S21
Brand: HPE
Capacity: 1.92TB
Interface: PCI Express 4.0 x4 (NVMe)
Form Factor: 2.5-inch Small Form Factor (SFF)
Connector Type: U.3 Universal Interface
Drive Type: Read Intensive (RI) Solid State Drive
Data Transfer Rate: Up to 32Gbps (PCIe Gen4 x4)
Sequential Read Speed: Up to 6,800 MB/s
Sequential Write Speed: Up to 2,800 MB/s
Random Read (4K): Up to 900,000 IOPS
Random Write (4K): Up to 110,000 IOPS
Endurance Rating: 1 DWPD (Drive Write Per Day)
NAND Flash Type: 3D TLC NAND
Latency (Read/Write): <0.1 ms / <0.2 ms
Power Consumption (Active): ~10W typical
Power Consumption (Idle): ~4W typical
Reliability (MTBF): 2 Million Hours
Operating Temperature: 0°C to 70°C
Hot-Pluggable: Yes
Dimensions: 2.5-inch Small Form Factor (SFF)
