P26372-B21 HPE 800GB SAS 12Gbps Write Intensive 2.5-inch Internal SSD

P26372-B21 Technical Specifications

HPE 800GB SAS 12Gbps Write Intensive 2.5-inch Internal SSD

Brand HPE
Product Line HPE Write Intensive
Model PM6
Manufacturer HP CTO Server Avnet

Storage
Data Transfer Rate (Hard Drive) 2.25 GBps
Endurance (DWPD) 10
Endurance Type 14267 TB
Form Factor (Short) 2.5″
Form Factor (Short) (metric) 6.4 cm
Hard Drive Capacity 800 GB
Hard Drive Features
Digitally Signed Firmware
Hard Drive Type
Hot-swap hard drive
HD Interface
Serial Attached SCSI 4
Max Internal Data Transfer Rate 1080 MBps
Max Write Transfer Rate 1035 MBps
NAND Flash Memory Type
Triple-level cell (TLC)
Storage Interface
Serial Attached SCSI 4
4KB Random Read 173000 IOPS
4KB Random Write 130000 IOPS

Connectivity
Interface Provided
1 x SAS 22.5Gb/s

Power
Power Consumption
2.84 Watt (idle), 5.37 Watt (random read), 5.37 Watt (random read/write), 5.37 Watt (random write), 6.45 Watt (sequential read), 9.64 Watt (maximum), 9.64 Watt (sequential write)

Technical Information
Compatible Bay 2.5″ SFF
Hard Drive Form Factor 2.5″ SFF
Hard Drive Form Factor (metric) 6.4 cm SFF

Product Information
Bundled With
HPE Smart Carrier
Packaged Quantity 1
Product Type Solid state drive

Dimensions & Weight
Height 0.6 inch
Weight 17.64 ounce
