PRIME TRX40-PRO Technical Specifications

ASUS S sTRX4 AMD TRX40 SATA 6Gb/s ATX AMD Motherboard

Model
Brand
ASUS
Model
PRIME TRX40-PRO S
Supported CPU
CPU Socket Type
sTRX4
CPU Type
AMD Socket sTRX4 for 3rd Gen AMD Ryzen Threadripper Series Desktop Processors
Chipsets
Chipset
AMD TRX40
Memory
Number of Memory Slots
8×288pin
Memory Standard
DDR4 4666(O.C.)/ 4600(O.C)/ 4400(O.C)/ 4333(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3200/ 2933/ 2800/ 2666/ 2400/ 2133 MHz ECC and non-ECC, Un-buffered Memory
Maximum Memory Supported
256GB
Channel Supported
Quad Channel
Expansion Slots
PCI Express 4.0 x16
3rd Gen AMD Ryzen Threadripper Desktop Processors
– 3 x PCIe 4.0 x16 Safeslots (supports x16/x16/x16 mode)*
* Recommend you to install add-on cards on (PCIEX16_1 and PCIEX16_2) or (PCIEX16_1 and PCIEX16_3) to enjoy 2 way SLI or CrossFireX.
PCI Express x4
AMD TRX40 chipset:
1 x PCIe 4.0 (x4 mode)
Other Slots
1 x M.2 Socket (Key E), supports type 2230 PCIe Wi-Fi/BT module*
* The Wi-Fi/BT module is purchased separately
Storage Devices
SATA 6Gb/s
8 x SATA 6Gb/s
M.2
3rd Gen AMD Ryzen Threadripper Series Desktop processors:
2 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIe 4.0 x4 mode)
AMD TRX40 chipset:
1 x M.2 Socket 3, with vertical M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIe 4.0 x4 mode)
SATA RAID
0/1/10
Onboard Audio
Audio Chipset
Realtek ALC S1220 High Definition Audio CODEC featuring Crystal Sound 3
Audio Channels
8 Channels
Onboard LAN
LAN Chipset
Intel i211AT
Max LAN Speed
10/100/1000Mbps
Rear Panel Ports
Back I/O Ports
1 x LAN (RJ45) port(s)
4 x USB 3.2 Gen 2 (teal blue) (3 x Type-A + 1 x Type-C) (one port can be switched to USB BIOS FlashBack)
6 x USB 3.2 Gen 1 (blue)
1 x Optical S/PDIF out
5 x Audio jack(s)
1 x USB BIOS FlashBack Button(s)
