R1N28A HPE 3032Q 32-Ports 100GBase-X QSFP28 Switch
R1N28A Overview
The HPE R1N28A 3032Q is a high-performance, fixed 1U data center switch designed to deliver 32x QSFP28 100 Gigabit Ethernet ports for ultra-fast networking in enterprise, cloud, and service provider environments. It belongs to the HPE FlexFabric/Aruba 3000 Series family, purpose-built for high-density, low-latency, and scalable networking infrastructures.With QSFP28 interfaces, the switch provides 32 x 100GbE ports, supporting flexible breakout options into 4x 25GbE or 2x 50GbE per QSFP28, giving versatility for mixed-speed environments. This makes it highly suitable for spine-leaf architectures, high-bandwidth workloads, and east-west traffic optimization in modern data centers.
R1N28A Technical Specifications
HPE 3032Q 32-Ports 100GBase-X QSFP28 Switch
Manufacturer Part Number: R1N28A
Brand Name: HPE
Product Type: Managed Layer 3 Data Center Switch
Total Ports: 32
Port Type: 32 x 100G QSFP28
Switching Capacity: 6.4 Tbps
Forwarding Rate: 2,380 Mpps
Layer Support: Layer 2 / Layer 3
MAC Address Table: 512,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Routing: Static, OSPF, BGP, IPv4/IPv6
Link Aggregation: IEEE 802.3ad LACP
Quality of Service (QoS): 8 queues, DSCP, IEEE 802.1p
Security: 802.1X, ACLs, RADIUS, TACACS+, MACsec (optional)
Management: CLI, Web GUI, SNMP, REST API, NetEdit
High Availability: MLAG, ECMP, VRRP
Form Factor: 1U Rack-mountable
Power Supply: Dual hot-swappable PSUs
