R8S89-61001 HP 24x SFP+ PoE Class6 2x SFP56 2x SFP28 GbE Switch
R8S89-61001 Overview
The HP R8S89-61001 is a high-performance Layer 3 managed switch designed for enterprise, campus, and data center edge deployments requiring 10GbE access with flexible uplink capacity. It provides 24x SFP+ ports supporting 1/10GbE fiber connections with PoE Class 6 support, making it suitable for powering high-performance devices such as Wi-Fi 6/6E access points, IP cameras, and IoT endpoints over fiber-powered solutions.In addition to access ports, the switch is equipped with 2x SFP56 uplink ports supporting up to 50GbE, and 2x SFP28 uplink ports supporting 25GbE, enabling flexible high-speed uplinks to aggregation or core layers. This ensures smooth scalability for high-bandwidth applications and hybrid network designs.
R8S89-61001 Technical Specifications
HP 24x SFP+ PoE Class6 2x SFP56 2x SFP28 GbE Switch
Manufacturer Part Number: R8S89-61001
Brand Name: HPE
Product Line: HPE Networking
Product Type: Managed Gigabit Ethernet Switch
Total Ports: 28
10-Gigabit Ethernet Ports: 24 x 10GbE SFP+ (PoE Class 6)
25-Gigabit Ethernet Ports: 2 x 25GbE SFP28
50-Gigabit Ethernet Ports: 2 x 50GbE SFP56
Switching Capacity: 1.2 Tbps
Forwarding Rate: 895 Mpps
Layer Support: Layer 2 / Layer 3
MAC Address Table: 128,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: STP, RSTP, MSTP
Routing: Static & Dynamic IPv4/IPv6, OSPF, BGP, VRF, ECMP
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service (QoS): 8 hardware queues, DSCP, IEEE 802.1p
