ROG-STRIX-RX5700XT-O8G-GAMING Technical Specifications
ASUS ROG STRIX AMD Radeon RX 5700 XT Overclocked 8G GDDR6 HDMI DisplayPort Gaming Graphics Card
Model
Brand
ASUS
Series
ROG Strix
Model
ROG-STRIX-RX5700XT-O8G-GAMING
Interface
Interface
PCI Express 4.0
Chipset
Chipset Manufacturer
AMD
GPU Series
AMD Radeon RX 5700 Series
GPU
Radeon RX 5700 XT
Core Clock
OC Mode: 1840 MHz
Gaming Mode: 1770 MHz
Boost Clock
OC Mode: 2035 MHz
Gaming Mode: 2010 MHz
Stream Processors
2560 Stream Processors
Memory
Effective Memory Clock
14 Gbps
Memory Size
8GB
Memory Interface
256-Bit
Memory Type
GDDR6
3D API
OpenGL
OpenGL 4.6
Ports
HDMI
1 x HDMI 2.0b
Multi-Monitor Support
6
DisplayPort
3 x DisplayPort 1.4
Details
Max Resolution
7680 x 4320
CrossFireX Support
Yes
Virtual Reality Ready
Yes
Cooler
Triple Fans
Thermal Design Power
225W
System Requirements
Recommended PSU: 600W
Power Connector
2 x 8-Pin
HDCP Ready
2.3
Features
Features
Axial-tech fan design features longer fan blades and a unique barrier ring to increase air pressure.
0dB Technology lets you enjoy light gaming in relative silence.
2.7-slot Design expands cooling surface area to make the most of the three powerful Axial-tech fans.
Auto-Extreme Technology uses automation to enhance reliability.
Super Alloy Power II includes premium alloy chokes, solid polymer capacitors, and an array of high-current power stages.
MaxContact Technology allows 2X more contact with the GPU chip for improved thermal transfer.
A reinforced frame prevents excessive torsion and lateral bending of the PCB.
ASUS FanConnect II equips 2 hybrid-controlled fan headers for optimal system cooling.
Aura Sync compatibility lets you customize and sync lighting effects with other compatible hardware.
GPU Tweak II provides intuitive performance tweaking, thermal controls, and system monitoring.
Form Factor & Dimensions
Max GPU Length
305 mm
Card Dimensions (L x H)
12.00″ x 5.10″
Slot Width
2.7 slot
Packaging
Package Contents
Accessories:
1 x Quick Guide
1 x ROG Velcro Hook & Loop
