SDFBE74DUB01 Toshiba 3.84TB SAS 12Gb/s Solid State Drive
SDFBE74DUB01 Overview
The Toshiba SDFBE74DUB01 PM5-R 3.84 TB Triple-Level Cell SAS 12 Gb/s SED FIPS Read-Intensive 2.5-inch Solid State Drive is a high-capacity enterprise SAS SSD designed primarily for read-intensive workloads in data centers, servers, and storage systems where secure, reliable data access is critical. It uses a 12 Gb/s SAS-3 interface in a 2.5-inch hot-swappable form factor, making it compatible with standard enterprise server bays and redundant SAS controllers. The drive is built with BiCS FLASH™ TLC NAND memory and tuned for read-intensive performance, typically achieving sequential read and write speeds around 2,100 MB/s and random read performance up to ~370,000 IOPS.
SDFBE74DUB01 Technical Specifications
Toshiba PM5-R 3.84TB Triple Level Cell SAS 12Gb/s SED FIPS Read Intensive 2.5-Inch Solid State Drive
Manufacturer : Toshiba
Manufacturer Part Number : SDFBE74DUB01
Product Series : Pm5-r
Product Type : Solid State Drive
Technical Information :
Storage Capacity : 3.84tb
Form Factor : 2.5 Inch
Interface : Sas-3.0
Interface Speed : 12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit
Memory Type : Bics Flash Tlc
Mttf : 2,500,000 Hours
Dwpd : 1
Performance :
Sustained 128 Kib Sequential Read : 2,100 Mb/s
Sustained 128 Kib Sequential Write : 2,100 Mb/s
Sustained 4 Kib Random Read : 370k Iops
Sustained 4 Kib Random Write : 55k Iops
Power :
Supply Voltage : 5 V
Power Consumption (ready) : 5.0 W Typ
Physical Characteristics :
Height : 15.0 Mm + 0, -0.5 Mm
Width : 69.85 Mm
Length : 100.45 Mm Max
Weight : 130 G Max
