SMT1500RM2UNC Technical Specifications
APC Smart-UPS 1500VA LCD RM UPS 1000 W 1440 VA with APC UPS Network Management Card
Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS
Model :1500VA LCD RM
Bundled with :APC UPS Network Management Card
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :Ethernet, USB
Expansion Slots
Expansion Slots :1 (total) / 0 (free) x SmartSlot
Interface Provided
Interfaces :1 x management (USB) – 4 pin USB Type B, Management (Ethernet) – RJ-45
Cable Details
Cables Included :Power cable
Power Device
Form Factor :Rack-mountable
UPS Technology :Line interactive
Voltage Provided :AC 120V
Voltage Provided Margin :± 5%
Frequency Provided :57 – 63 hertz
UPS Output Waveform :Sinewave
Power Provided :1000 watt
Power Capacity (VA) :1440 volt ampere per kilogram 1440VA
Voltage Required :AC 120 volt
Input Voltage Range :AC 82 – 144 V
Input Voltage Range (Adjustable) :AC 75 – 154 V
Frequency Required :50/60 hertz
Input Connector Type :Power NEMA 5-15
Input Connector Qty :1
Output Connector Qty :6
Surge Energy Rating :459 joules
Power Device Features :LCD display, LED indicators, Audible alarm
Power Output Connectors Details
Power Output Connectors Details :6 x power NEMA 5-15
Battery
Run Time (Up To) :7 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Run Time Details
Run Time (Up To) :9 min at 900 Watts, 11 min at 800 Watts, 26 min at 500 Watts, 7 min at 1000 Watts, 92 min at 200 Watts, 14 min at 700 Watts, 7 min at full load, 190 min at 100 Watts, 56 min at 300 Watts, 37 min at 400 Watts, 26 min at half load, 335 min at 50 Watts, 19 min at 600 Watts
UPS
Batteries Qty :1
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Height (Rack Units) :2
Compliant Standards :CSA, RoHS, FCC Class A certified, REACH, FCC Part 15, UL 1778
Environmental Standards
ENERGY STAR :Yes
Dimensions & Weight
Width :17 inch
Depth :18 inch
Height :3.5 inch
Weight :63.14 lbs
Dimensions & Weight (Shipping)
Shipping Width :23.4 inch
Shipping Depth :23.7 inch
Shipping Height :9.9 inch
Shipping Weight :70.35 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95%
Sound Emission :46 dBA
