SR3B4 Intel Xeon Gold 6152 22-Core 2.10GHz 10.40GT/s UPI Processor

SR3B4 Technical Specifications

Intel Xeon Gold 6152 22-Core 2.10GHz 10.40GT/s UPI Processor

Processor Type Server
Series Xeon Gold Processor
Core Model Type/Proc No. 6152
Processor Code Name Skylake
Core Stepping H0
Manufacturing Technology 14 nm
# of Cores 22
# of Threads 44
Clock Speed 2.10 GHz
L3 Cache Size 30.25 MB
Front Side Bus / Quick Path Interconnect 10.40 GT/s
Thermal Power 140 Watts
Max Memory Size 768 GB
Memory Types DDR4-2666
Maximum Memory Speed 2666 MHz
Memory Channels 6
ECC Memory Supported Yes
CPU Socket Type LGA 3647
Package Size 76.0mm x 56.5mm
TCASE 92 °C
Embedded Options Available No
Scalability S4S
PCI Express 3.0
