UCS-OPS-C220M4S-01 Technical Specifications
Cisco Systems Ucs C220M4S 2XE52630 V3
General Information
Product Name Cisco Ucs C220M4S 2XE52630 V3 4X16GB Memory 2X1TB
Manufacturer Part Number UCS-OPS-C220M4S-01
Product Series C220 M4
Product Type Server
Controllers
Controller Type Serial SATA/600
RAID Supported Yes
RAID Levels 0, 1, 10
Display & Graphics
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200e
Graphics Memory Capacity Up to 8 MB
Memory
Standard Memory 64 GB
Maximum Memory 1.50 TB
Memory Technology DDR4 SDRAM
Memory Slots: 24 x DDR4 RAM Slots
Network & Communication
Ethernet Technology Gigabit Ethernet
Power Description
Input Voltage 120 V AC
230 V AC
Storage
Total Hard Drive Capacity 2 TB
Hard Drive Interface Serial SATA
Hard Drive Configuration 2 x 1 TB
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Xeon
Processor Model E5-2630 v3
Processor Core Octa-core (8 Core)
Processor Speed 2.40 GHz
Physical Characteristics
Form Factor Rack
Rack Height 1U Rack Mount
Height 1.7″
Width 19″
Depth 31″
