UCSB-B420-M4-CH Cisco UCS B420 M4 Blade Server – blade
UCSB-B420-M4-CH Overview
Designed for demanding virtualization and database workloads, the B420 M4 combines a large memory footprint with 4-socket scalability, using the Intel Xeon processor E5-4600 v3 product family. The blade server supports 2133 MHz DDR4 memory and utilizes Cisco UCS virtual interface card technology to achieve up to 160 Gbps aggregate I/O bandwidth, all in a dense, full-width blade form factor.
$4,599
Buy NowUCSB-B420-M4-CH Technical Specifications
Cisco UCS B420 M4 Blade Server – blade
Bay Provided
Form Factor :2.5″ SFF
Free Qty :4
Total Qty :4 Bays
Card Reader
Supported Flash Memory Cards :SD Memory Card
Chassis
Form Factor :Blade
Front Accessible Bays Qty :4
Hot-Swap Bays Qty :4
Manufacturer Form Factor :Blade Server
Server Storage Bays :Hot swap
Server Swappable Drive Form Factor :2.5″
Server Swappable Drive Form Factor (metric) :6.4 cm
Server Swappable Drive Interface :SAS
Dimensions & Weight
Depth :24.4 in
Height :2 in
Weight :17.86 lbs
Width :16.5 in
Display
Type :None.
Expansion Bays
Form Factor (metric) :6.4 cm SFF
Type :Hot-swap
Expansion Slots
Type :CPU
Type :DIMM 288-pin
Type :Expansion slot
Type :SDHC Card
Hard Drive
Type :No HDD
Hard Drive (3rd)
Type :None
Header
Brand :Cisco
Compatibility :PC
Manufacturer :Cisco Unified Computing
Model :B420 M4 Blade Server
Packaged Quantity :1
Product Line :Cisco UCS
Interface Provided
Location :1 internal
Type :USB 2.0
Qty :1
Type :KVM
Mainboard
Chipset Type :Intel C612
Processor Socket :LGA2011 Socket
Miscellaneous
Color Category :Gray
Compliant Standards :21 CFR 1040.10, AS/NZS 60950-1 Second Edition, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CNS 13438(95) Class A, EN 300 386, EN 300386, EN 60950-1 Second Edition, EN55022 Class A, EN55024, EN61000-3-2, EN61000-3-3, FCC CFR47 Part 15, GB 4943-2001 PSB, ICES-003 Class A, IEC 60950-1 Second Edition, KN22 Class A, KN24, UL 60950-1, VCCI Class A
Pricing Type :Upgrade
Networking
Remote Management Controller :Cisco Integrated Management Controller
Optical Storage
Drive Type :No optical drive
Type :None
Optical Storage (2nd)
Type :None
Printer
Type :None
Processor
Max Supported Qty :4
Server Scalability :4-way
Type :No CPU
Upgradability :Upgradable
RAM
Data Integrity Check :ECC
Empty Slots :48
Features :Registered
Form Factor :DIMM 288-pin
Installed Size :0 GB
Max Supported Size :3 TB
Slots Qty :48 DDR4 Slots
Technology :DDR4 SDRAM
