Wave-PRO Ubiquiti UISP 60GHz/5GHz Wave Professional Radio
Wave-PRO Overview
Ubiquiti UISP 60GHz/5GHz Wave Professional Radio. Ubiquiti’s is a high-capacity 60GHz radio system with 5GHz backup radio, an integrated high-gain antenna, 2x 2.5Gbps Ethernet Ports, 1x 10Gbps SFP+ as well as integrated GPS and precision mount bracket. It features Wave technology with true duplex gigabit performance PtP links up to 15 km. In PtMP mode, it can be used as a CPE and paired with the (up to 8km) or (6km) with a total throughput of up to 5.4Gbps.
Wave-PRO Technical Specification
Ubiquiti UISP 60GHz/5GHz Wave Professional Radio
Manufacturer: Ubiquiti
Brand: Ubiquiti
Antenna Gain: 60GHz: 46dBi ; 5.8GHz: 22dBi
Beamwidth: 60GHz: 1.3° ; 5GHz: 8°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 1200Mbps
Ethernet Ports: 2x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 26W
Dimensions: Ø424.4 x 166.2mm
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 44–54V or 22–27V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Other: 1x SFP+
