WDS250G3B0B WD Blue SA510 – SSD – 250 GB – SATA 6Gb/s

WDS250G3B0B Technical Specifications

WD Blue SA510 – SSD – 250 GB – SATA 6Gb/sx

Brand WD
Product Line WD Blue SA510
Model WDS250G3B0B
Manufacturer Western Digital

Storage
Data Transfer Rate (Hard Drive) 600 MBps
Endurance Type 100 TB
Form Factor (Short) M.2
Form Factor (Short) (metric) M.2
Hard Drive Capacity 250 GB
Hard Drive Type
Internal hard drive
HD Interface Serial ATA-600
Max Internal Data Transfer Rate 555 MBps
Max Write Transfer Rate 440 MBps
Storage Interface
Serial ATA-600 4KB Random Read
80000 IOPS 4KB Random Write
78000 IOPS

Connectivity
Interface Provided
1 x SATA 6 Gb/s

Power
Power Consumption
12 mW (DevSleep), 1800 mW (read), 2000 mW (write), 36 mW (sleep), 50 mW (active)

Software
Software Type
Acronis True Image, Dropbox Professional (free for 3 months)

Technical Information
Compatible Bay M.2 2280
Hard Drive Form Factor M.2 2280
Hard Drive Form Factor (metric) M.2 2280
Max Operating Temperature 158 degree Fahrenheit
Min Operating Temperature 32 degree Fahrenheit
MTBF 1,750,000 Hours
Shock Acceleration (Operating) 1500 gram
Shock Duration (Operating) 0.5 ms half-sine
Vibration Acceleration (Non-operating) 4.9 gRMS
Vibration Acceleration (Operating) 5 gRMS
Vibration Frequency Range (Non-operating) 7-800 Hz
Vibration Frequency Range (Operating) 10-2000 Hz

Product Information
Packaged Quantity 1
Product Type Solid state drive

Dimensions & Weight
Height 0.1 inch
Weight 0.17 ounce
Width 0.9 inch
Depth 3.1 inch
