WDS400T1X0L Technical Specifications
WD_BLACK AN1500 solid state drive 4TB PCI Express
Manufacturer :Western Digital
Brand :WD
Product Line :WD_BLACK AN1500
Model :WDS400T1X0L-00AUJ0
Country Kits :Worldwide (excluding China)
Packaged Quantity :1
Storage
Type :Solid state drive
Hard Drive
Hard Drive Type :Internal hard drive
Form Factor :PCIe card
Form Factor (metric) :PCIe card
Form Factor (Short) :PCIe card
Form Factor (Short) (metric) :PCIe card
Storage Interface :PCI Express 3.0 x8 (NVMe)
Interface :PCI Express 3.0 x8 (NVMe)
Capacity :4 TB
Integrated Heatsink :Yes
Internal Data Rate :6500 MBps
Internal Data Rate (Write) :4100 MBps
4KB Random Read :780000 IOPS
4KB Random Write :710000 IOPS
Features :Integrated heatsink, RGB lighting
Interface Provided
Interfaces :1 x PCI Express 3.0 x8 (NVMe)
Bay Required
Compatible Bay :PCIe card
Software
Type :WD SSD Dashboard
Power Consumption
Power Consumption :12.8 Watt (write), 15.7 Watt (read), 8.5 Watt (idle)
System Requirements
OS Required :Windows 10 (64-bit)
Miscellaneous
MTBF :1,750,000 Hours
Compliant Standards :CB, FCC, UL
Dimensions & Weight
Width :2.8 inch
Depth :6.9 inch
Height :0.5 inch
Weight :7.41 ounce
Dimensions & Weight (Shipping)
Shipping Width :9.1 inch
Shipping Depth :1.8 inch
Shipping Height :6.7 inch
Shipping Weight :14.46 ounce
