Refurbished WS-C3560X-24T-E Cisco Catalyst 3560X 24 Port

Refurbished WS-C3560X-24T-E Overview

Cisco Catalyst WS-C3560X-24T-E is 24 Gigabit Ethernet ports standalone switch with four optional 1G/10G network uplink module and no option to stack in IP service feature set. IP service feature set provides up to 1005-Vlans and advanced layer 3 routing features, advanced security features and management features. WS-C3560X-24T-E is designed for enterprise distribution layer switching in full layer 3 capability includes BGP, EIGRP, OSFP, IPv4/v6, multicast routing, IPSLA, Netflow, advanced Qos, VRF-lite. WS-C3560X-24T-S switch comes with one default power supply module, customers can purchase additional power supply module insert into power supply bay 2 in order to power redundancy.


Buy Now
Availability: In Stock

Refurbished WS-C3560X-24T-E Technical Specification

Cisco Catalyst 3560X 24 Port Data IP Services

General Information
Manufacturer Cisco Systems, Inc
Manufacturer Part Number WS-C3560X-24T-E
Brand Name Cisco
Product Line Cisco Catalyst
Product Series C3560X
Product Name Catalyst Ethernet Switch
Product Type Ethernet Switch
Total Number of Network Ports 24
Token Ring Port No
LRE Port No
Uplink Port No
Bypass No
Modular No
Management Port Yes
Number of Network (RJ-45) Ports 24
Media & Performance
Media Type Supported Twisted Pair
Ethernet Technology Gigabit Ethernet
Network Technology 10/100/1000Base-T
I/O Expansions
Number of Total Expansion Slots 1
Shared SFP Slot No
Network & Communication
Layer Supported 2
Standard Memory 256 MB
Memory Technology DRAM
Flash Memory 64 MB
MTBF 208218 Hour
Power Description
PoE (RJ-45) Port No
Input Voltage 110 V AC
Input Voltage 220 V AC
Power Source Power Supply
Redundant Power Supply Yes
