XP800LE10005 Seagate 800GB PCI E NVMe Solid State Drive
XP800LE10005 Overview
The Seagate XP800LE10005 Nytro 5350M 800 GB NVMe SSD is an enterprise‑class internal solid‑state drive engineered for mixed‑use workloads in servers and storage systems that support the PCIe 4.0 ×4 NVMe interface. Built in a 2.5‑inch U.2 form factor, it fits hot‑swappable enterprise bays and delivers a strong balance of performance, reliability, and storage density.
Using Triple‑Level Cell (TLC) NAND flash and enterprise‑tuned firmware, this SSD delivers very fast sequential and random performance compared with SATA or PCIe 3.0 drives, helping improve system responsiveness, application load times, and data transfer speeds in environments like virtualization, database acceleration, analytics, and mixed operational workloads. The ~800 GB capacity provides ample room for performance tiers, metadata volumes, cache layers.
$576
XP800LE10005 Technical Specifications
Seagate Nytro 5350M 800GB Triple-Level Cell PCI Express NVMe 4.0 x4 Mixed Use 2.5-In Solid State Drive
Manufacturer : Seagate
Manufacturer Part Number : XP800LE10005
Storage Capacity: 800 GB
Internal solid state drive
Mixed‑use (balanced read/write) SSD
Triple‑Level Cell (TLC) NAND
Interface & Form Factor
PCI Express 4.0 x4 (NVMe)
U.2 / 2.5‑inch form factor
7 mm height
Performance
Sequential read up to ~6000 MB/s
Sequential write up to ~1900 MB/s
Random read ~945,000–1,000,000 IOPS
Random write ~140,000 IOPS
Endurance & Reliability
Endurance ~3 DWPD (Drive Writes Per Day)
Total Bytes Written ~4300 TBW
Enterprise‑grade reliability and error management
Power & Environment
Active power typical for enterprise NVMe SSDs
Operating temperature suitable for data center use
Physical
2.5‑inch enterprise SSD
Compact 7 mm height suitable for dense server bays
