7726-32X-O-AC-F-US Edge-Core Switch 32 ports Rack-mountable
7726-32X-O-AC-F-US Overview
The Edge-Core AS7726-32X switch is a Top-of-Rack (TOR) or spine switch for high-performance data centers. In a compact 1RU form factor, the switch provides line-rate L2 and L3 switching across the 32 x QSFP28 ports, and each QSFP28 port can be configured as 2x50G, 4x25G, 1x40GbE or 4x10GbE by using DAC breakout cables.
$8,385
7726-32X-O-AC-F-US Technical Specifications
Edge-Core AS7726-32X Switch 32 ports Managed Rack-mountable
Device Type: Switch – 32 ports – L3 – managed
Enclosure Type: Front to back airflow rack-mountable 1U
Subtype: 100 Gigabit Ethernet
Ports: 32 x 100 Gigabit QSFP28
Capacity: VLAN IDs: 4000
MAC Address Table Size: 288K entries
Jumbo Frame Support: 9216 bytes
Processor: 1 x Intel Xeon D-1500 series: 2.2 GHz
RAM: 16 GB – SO-DIMM 260-pin – DDR4 SDRAM
Flash Memory: 64 GB
Built-in Devices: 64 GB SSD
Expansion / Connectivity
Power: Power Device
Internal power supply – hot-plug
Installed Qty: 2
Max Supported Qty: 2
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Miscellaneous
Software / System Requirements
Dimensions & Weight
Width: 17.3 in
Depth: 20.3 in
Height: 1.7 in
Weight: 23.96 lbs
Environmental Parameters
Min Operating Temperature: 32 °F
Max Storage Temperature: 158 °F
