Refurbished 795236-B21 HP Proliant Dl360 Gen9 Server

Refurbished 795236-B21 Technical Specifications

HP Proliant Dl360 G9 Oneview Model 2x Intel Xeon 12-Core E5-2670v3/ 2.3GHz, 64GB Ddr4 Sdram, 1GB 331flr Ethernet & 10GB 533flr-T Flexfabric Adapter, 2x 800w Ps 1u Rack Server.

GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 795236-B21
Product Name: Proliant Dl360 Gen9 – 1u Rack Mount Server (Oneview Model)
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon E5-2670v3 / 2.3 Ghz
Max Turbo Speed : 3.1 Ghz
Quickpath Interconnect : 9.60 Gt/S
Number Of Cores : 12 Core
64-Bit Computing : Yes
Compatible Processor Socket : Fclga2011-3
Installed Qty : 2
Max Supported Qty : 2
Chipset Type : Intel C610 Series
CACHE MEMORY :
Cache Memory Type : Smart Cache
Installed Size : 60 Mb
Cache Per Processor : 30 Mb
MEMORY :
Installed Size : 64 Gb / 384 Gb (Max)
Technology : Ddr4 Sdram – Advanced Ecc
Memory Speed : 2133 Mhz
Memory Specification Compliance : Pc4-17000
Form Factor : Dimm 288-Pin
Memory Slots: 24 x DDR4 RAM Slots
Features : Registered, Online Spare Memory, Quad Channel Memory Architecture, Hp Smartmemory
Configuration Features : 4 X 16 Gb
Ram Supported : Pc4-17000 – 768 Gb – Load-Reduced ¦ Pc4-17000 – 384 Gb – Registered
STORAGE:
Hard Drive : None
Optical Drive : None
STORAGE CONTROLLERS:
Storage Controller Name : Smart Array P440ar
Buffer Size : 2 Gb
Disk Drive : 12gb/S Sas / 6gb/S Sata
Sas Port Link Rate : 12gb/S Per Physical Link Supported
Pcie Link Rate : Pci Express 3.0 X8 (Pcie3 X8)
Physical Drives : Up To 26 Drives
Logical Drives Supported : Up To 64 Logical Drives
Raid Support : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60, Raid 1 Adm, Raid 10 Adm
DISPLAY & GRAPHICS CONTROLLERS :
Type : Integrated
Graphics Processor : Matrox G200
Video Interfaces : Vga
NETWORK & COMMUNICATION:
Ethernet Ports : 2 X 10 Gigabit Ethernet, 4 X Gigabit Ethernet
Ethernet Controller : Hp 331i, Hp 533flr-T
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
POWER DESCRIPTION :
Device Type : Flex Slot Platinum Plus Hot-Plug Power Supply
Installed Qty : 2
Max Supported Qty : 2
Nominal Voltage : Ac 100-240v (50/60 Hz)
Power Provided : 800 Watt
