C1300-24XT Technical Specifications
Cisco Catalyst 1300 24-Port 10G Ethernet Switch
Part Number: C1300-24XT
Series: Cisco Catalyst 1300 Series
Type: Layer 3 Managed Ethernet Switch
Total Ports: 24
Ethernet Ports: 24 x 1G/10G RJ-45
Uplink Ports: 4 x 10G SFP+
Switching Capacity: 320 Gbps
Forwarding Rate: 238 Mpps
MAC Address Table: 32,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: STP, RSTP, MSTP
Routing Protocols: IPv4/IPv6 Static Routing, RIP, Policy-Based Routing
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service: 8 Queues, IEEE 802.1p, DSCP, CoS
Security: 802.1X, ACLs, Port Security, DHCP Snooping, DoS Prevention
Management: Web GUI, CLI, SNMP v1/v2c/v3, RMON, Syslog
Stacking Capability: Up to 8 units
Port Mirroring: Supported
LED Indicators: Power, System, Link/Activity, Speed
Form Factor: 1U Rack-mountable
