FSP300UCB-B204 Sparkle Power 300 Watts Power Supply

FSP300UCB-B204 Technical Specifications

Sparkle Power 300 Watts 1U Rack Mount Power Supply

Manufacturer: Sparkle Power, Inc
Manufacturer Part Number: FSP300UCB-B204
Product Type: AC to DC Power Supply
Input Voltage: 90 to 264 VAC
Output Voltage: 3.3V|5V|12V|-12V|5Vsb
Maximum Current Rating: 6A @ 115VAC
Maximum Output Current: 6.59A|7.69A|18.82A|0.23A|2.26A
Maximum Output Power: 300 W
Efficiency: 85%
Number of Outputs: 5
Input Frequency: 47 Hz to 63 Hz
Minimum Isolation Voltage: 1800V
Agency Approvals: UL|CSA|TUV|CB
Minimum Operating Temperature: 0°C
Maximum Operating Temperature: 50°C
Length: 190 mm
Width: 100 mm
Height: 40.5 mm
